Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF803
AirTAC X-ABF803 Fitting - Locknut Internal Thread Straight Terminal Specifications
- Model: X-ABF803
- Type: Straight terminal with internal thread & locknut
- Thread standard: BSPP (G thread)
- Thread size: G1/8 (R1/8 optional)
- Material: Brass with nickel plating
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 100℃
- Surface roughness: Ra ≤1.6μm
- Seal type: Metal-to-metal seal (PTFE tape required)
- Installation torque: 12-15 N·m (recommended)
- Weight: 18g ±0.5g
- Dimensions: 30mm(L) × 18mm(W) × 18mm(H)
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Corrosion resistance: 96hr salt spray test passed
Heavy-duty straight connector featuring precision-machined threads and anti-vibration locknut design. The nickel-plated brass construction ensures corrosion resistance in humid environments. Includes dual O-ring grooves for optional secondary sealing. Compatible with air, water, and inert gas systems.
- Pneumatic cylinder port connections
- Compressed air distribution manifolds
- CNC machine tool coolant lines
- Vacuum system interface points
- Industrial robot end-effector plumbing
Installation protocol:
Apply 3-5 wraps of PTFE tape clockwise on male threads. Hand-tighten
before final torque adjustment. Use two wrenches to prevent rotation
strain – one on hex body (18mm) and another on locknut (22mm).
Do NOT use with:
Aggressive chemicals, high-pressure steam (>150℃), or systems
experiencing pressure spikes above 2.5MPa. Inspect every 6 months
for thread wear.
| Property | Property Value |
|---|---|
| sku | X-ABF803 |
