Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1003A
AirTAC X-ABL1003A Locknut Elbow Terminal Specifications
- Model: X-ABL1003A
- Type: 90° swivel locknut terminal
- Port size: 1/8" BSPP (G1/8)
- Thread specification: ISO 228-1 compliant
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm)
- Seal material: NBR O-ring (70±5 Shore A)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃
- Installation torque: 1.2-1.5 N·m
- Swivel angle: 360° continuous rotation
- Vibration resistance: ≤50 m/s²
- Weight: 28±2 grams
- Dimensions: 32mm(L) × 18mm(W) × 28mm(H)
- Compliance: RoHS 2.0 compliant
Precision-engineered elbow terminal with integrated swivel locknut, featuring anti-vibration teeth for secure tubing connections. The electroless nickel coating provides exceptional corrosion resistance in humid environments. Designed for zero-leak performance with dual-sealing structure (metal-to-metal + elastic seal).
- Pneumatic valve manifold port connections
- Robotic arm end-effector air supply lines
- CNC machine tool coolant control systems
- Semiconductor manufacturing equipment
- Food processing pneumatic circuits (FDA-compliant grease option available)
Installation protocol:
Use torque wrench for assembly. Apply thread sealant only on male threads (PT),
not required for BSPP connections. Perform pressure test at 1.75MPa after installation.
Maximum 5 reuses recommended for optimal sealing performance.
