Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1202
AirTAC X-ABL1202 Locknut Right Angle Terminal Specifications
- Model: X-ABL1202
- Thread specification: M5×0.8 (internal thread)
- Locknut thread: M12×1.25
- Material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Surface roughness: Ra≤1.6μm (sealing surfaces)
- Tightening torque: 0.4-0.6 N·m (threaded connections)
- Weight: 8g ±0.5g
- Dimensions: 20mm(L) × 16mm(W) × 16mm(H)
- Port orientation: 90° right angle configuration
- Vibration resistance: ≤10 Hz (continuous operation)
- Certification: RoHS compliant
Precision-engineered right angle terminal with integrated locknut, designed for space-constrained pneumatic connections. Features anti-vibration teeth (3-point locking design) and bubble-tight sealing. The nickel-plated brass construction ensures corrosion resistance in humid environments. Compatible with 4mm OD pneumatic tubing (push-in connection).
- Robotic arm pneumatic gripper installations
- CNC machine tool sensor connections
- Medical device gas line distribution
- Packaging machine air circuit branching
- Semiconductor manufacturing equipment
- Automated assembly line manifolds
Installation protocol:
Apply thread sealant (PTFE tape recommended) to M12×1.25 locknut threads.
Use calibrated torque wrench for final tightening - over-tightening may deform
sealing surfaces. Perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL1202 |
