Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL401A
AirTAC X-ABL401A Locknut Right Angle Terminal Specifications
- Model: X-ABL401A
- Type: Locknut-style right angle terminal (push-to-connect)
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile) rubber
- Thread specification: M5×0.8 female thread
- Tube compatibility: Ø4mm (1/8") OD pneumatic tubing
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 12.5g ±0.3g
- Dimensions: 24mm(L) × 16mm(W) × 20mm(H)
- Torque resistance: 0.49N·m min
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- IP rating: IP40 (non-submerged environments)
- Certification: RoHS compliant
- Color code: Silver body with black locknut
90° right-angle pneumatic connector with tool-free installation, designed for space-constrained pneumatic circuits. Features a knurled locknut for secure anti-vibration fastening and color-coded components for quick identification. The brass construction ensures durability in high-cycle applications.
- Robotic end-effector pneumatic connections
- Compact valve terminal block assemblies
- CNC machine tool air supply interfaces
- Medical device pneumatic manifolds
- Automated packaging line actuators
Installation note:
Insert tube until it bottoms out (audible click), then hand-tighten locknut.
Avoid overtightening - maximum torque 0.8N·m. For optimal seal life,
use with filtered air (≤40μm particles).
| Property | Property Value |
|---|---|
| sku | X-ABL401A |
