Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL601
AirTAC X-ABL601 Elbow Terminal with Locknut Specifications
- Model: X-ABL601
- Type: 90° elbow terminal with compression locknut
- Material: Nickel-plated brass body
- Thread specification: PT1/8 (G1/8 optional)
- Applicable tubing OD: 6mm (flexible pneumatic tubing)
- Working pressure: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Surface treatment: Electrolytic polishing
- Protection rating: IP40
- Weight: ~52g (including packaging)
- Dimensions: 30mm(L) × 20mm(W) × 25mm(H)
- Torque limit: 1.2-1.5 N·m (recommended installation torque)
Precision-engineered right-angle terminal featuring a compression locknut mechanism for secure tubing connections. The corrosion-resistant nickel plating and reinforced threading ensure 5000+ connection cycles. Includes integrated O-ring groove for positive sealing without additional fittings.
- Pneumatic valve manifold interconnections
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply distribution
- Compact sensor mounting configurations
- Vacuum system component integration
Installation protocol:
Hand-tighten locknut before applying final ¼ turn with wrench.
Use thread sealant only on male threads, never in compression area.
Maximum angular deviation: ±3° after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL601 |
