Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL602
AirTAC X-ABL602 Elbow Terminal with Locknut Specifications
- Model: X-ABL602
- Type: 90° elbow terminal with integrated locknut
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Thread specification: M5×0.8 external thread
- Tube OD compatibility: 6mm (1/4")
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal type: NBR O-ring (oil-resistant nitrile rubber)
- Installation torque: 1.2-1.5 N·m recommended
- Weight: 25g ±2g
- Dimensions: 32mm(L) × 22mm(W) × 18mm(H)
- Vibration resistance: ≤10-55Hz, 1.5mm amplitude
- Corrosion resistance: 96hr salt spray test compliant
Precision-engineered right-angle connector featuring dual-stage sealing with integrated anti-vibration locknut. The tapered thread design ensures leak-free connections in high-cycle applications. Electroless nickel plating provides enhanced wear resistance against repeated installations.
- Pneumatic valve terminal blocks in assembly robots
- Compact sensor mounting in packaging lines
- Medical device gas delivery systems
- Coolant line connections in CNC machinery
- Vacuum circuit junctions in semiconductor equipment
Installation protocol:
Hand-tighten until resistance is felt, then apply 1/4 turn with wrench.
Always use backup wrench on hex base during tightening.
Max 3 reuses recommended for critical pressure systems.
- Not compatible with PTFE tape – use liquid thread sealant if required
- Maximum angular deflection: ±2° from installed position
- Do not use with corrosive gases or liquid media
| Property | Property Value |
|---|---|
| sku | X-ABL602 |
