Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL802
$4.77
Regular price
$12.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABL802
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABL802 Lock Nut Right Angle Terminal Specifications
- Model: X-ABL802
- Type: Reusable 90° elbow terminal with locking nut
- Material: Nickel-plated brass for corrosion resistance
- Thread specification: M5×0.8 female thread (port side)
- Tube compatibility: Ø8mm (5/16") OD pneumatic tubing
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃ (-4°F to 248°F)
- Seal material: NBR (Nitrile) rubber
- Installation torque: 1.0-1.5 N·m recommended
- Weight: ~28g (0.062 lbs)
- Dimensions: 32mm(L) × 18mm(W) × 18mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
High-density right-angle connector featuring a swivel locking nut for secure tube retention in confined spaces. The dual-seal design prevents air leakage under vibration, with 360° rotatable body for flexible orientation adjustment. Compatible with PU/Nylon/PVC tubing.
Typical Applications:
- Compact pneumatic manifolds in robotics
- Tool changer interfaces on CNC machines
- Medical equipment gas line connections
- Mobile hydraulic control systems
- Packaging machine actuator circuits
Installation note:
Insert tube fully until it bottoms out before tightening lock nut.
Avoid overtightening - stop when resistance increases sharply.
Recommended reusability: ≤5 cycles while maintaining seal integrity.
| Property | Property Value |
|---|---|
| sku | X-ABL802 |
