Airtac X-AHVFS Hand Valve X-AHVFS1004
$10.76
Regular price
$18.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-AHVFS1004
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-AHVFS1004 Manual Hand Valve Specifications
- Model: X-AHVFS1004
- Type: 2-position manual shut-off valve (push-pull operation)
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Flow capacity: 550 L/min (ANR)
- Valve body material: Brass with chrome plating
- Seal material: Fluororubber (FKM)
- Temperature range: -20℃ to 80℃
- Weight: 480g ±5%
- Dimensions: 76mm(L) × 38mm(W) × 105mm(H)
- Port thread depth: 10mm engagement
- Actuation force: ≤20N
- Leakage rate: ≤3 bubbles/min (ISO 6952)
- Protection rating: IP67 (dust/water resistant)
Heavy-duty manual override valve with visual position indicator (green/red collar). Features zero-backlash lever mechanism for precise flow control and emergency line isolation. Compatible with compressed air and inert gases. Rated for 500,000+ cycles with ≤0.5% flow decay.
Typical Applications:
- Emergency stop systems in pneumatic production lines
- Maintenance bypass control for robotic welding cells
- Pressure vessel isolation in chemical processing
- Manual override for automated packaging machinery
- Safety lockout during equipment servicing
Installation note:
Mount in accessible locations with lever clearance ≥120° swing radius.
Apply 5-7Nm torque during port connection. Lubricate O-rings with
silicone grease (Parker O-Lube or equivalent) during assembly.
| Property | Property Value |
|---|---|
| sku | X-AHVFS1004 |
