Airtac X-AHVSS Manual Valve X-AHVSS0404B
AirTAC X-AHVSS0404B Manual Rotary Valve Specifications
- Model: X-AHVSS0404B
- Type: 4-port/5-position manual rotary valve (detent mechanism)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Flow capacity: 750 L/min (Cv=1.2)
- Valve body material: Anodized aluminum alloy
- Seal materials: NBR + Polyurethane composite
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Operating torque: ≤1.5N·m
- Weight: 0.8kg (1.76 lbs)
- Dimensions: 98mm(L) × 48mm(W) × 70mm(H)
- Port thread depth: 12mm (minimum engagement)
- Mounting options: Panel mount with M5 screw holes
- Protection rating: IP54 (standard)/IP65 (with optional cover)
Robust manual override valve featuring a tactile position indicator and positive detent engagement. The chrome-plated rotary knob with anti-slip grooves enables precise control in high-vibration environments. Features dual sealing layers for leak-free operation and corrosion-resistant anodized surfaces. Compatible with ISO 8573-1:2010 Class 3 compressed air standards.
- Emergency override in automated production lines
- Pneumatic system maintenance bypass control
- Mobile equipment manual pressure regulation
- Tooling fixture clamping sequence control
- Educational pneumatic training stations
Installation note:
Apply thread sealant only on male ports (not required for BSPP).
For vertical mounting, install exhaust port downward to prevent
condensation accumulation. Lubricate rotary shaft quarterly
with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | X-AHVSS0404B |
