Airtac X-AJSS Universal Throttle-Type Swivel Joint Connector X-AJSS604
AirTAC X-AJSS604 Swivel Joint-Throttle Type Specifications
- Model: X-AJSS604
- Type: 360° rotatable throttle swivel joint
- Body material: Anodized aluminum alloy (black finish)
- Seal material: HNBR (high-temperature nitrile)
- Port size: 1/4" BSPP (G1/4)
- Max flow rate: 1,500 L/min (at 0.5 MPa)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Rotation torque: ≤0.3 N·m
- Max tilt angle: ±25° from center axis
- Weight: 182g ±5g
- Dimensions: 62mm(L) × 34mm(W) × 34mm(H)
- Thread engagement depth: 12mm
- Pressure test: 1.5 MPa leakage check
- Vibration resistance: 10–55Hz, 1.5mm amplitude
Multi-axis adjustable pneumatic connector with integrated flow control, featuring dual-locking swivel mechanism for secure positioning. The chrome-plated brass throttle valve provides precise flow adjustment via 220° rotation knob (2–8 L/min fine-tuning range). Anti-vibration design prevents self-loosening under pulsation.
- Robotic welding arm pneumatic tool changers
- CNC machine coolant nozzle positioning
- Automated painting equipment rotary unions
- Food processing line air knife systems
- Semiconductor wafer handling robots
Installation protocol:
Apply 3–5Nm torque during assembly. Always align flow arrow with system direction.
For vertical mounting, install flow control knob upward to prevent particle accumulation.
Perform 3 full rotation cycles before initial pressurization.
Maintenance note:
Replace O-rings (AS568-016) every 500,000 cycles or 2 years.
Do not use silicone-based lubricants – compatible with PFPE grease only.
| Property | Property Value |
|---|---|
| sku | X-AJSS604 |
