Airtac X-APDJ Insert Type Tee Adapter X-APDJ6
AirTAC X-APDJ6 Insertion-Type Tee Fitting Specifications
- Model: X-APDJ6
- Type: Push-in straight tee connector
- Port configuration: 3-way (1 inlet / 2 outlets)
- Thread size: M5×0.8 (external thread)
- Material: Brass with nickel plating (body), PBT plastic (collet)
- Tube compatibility: Ø6mm pneumatic tubing (4-6mm OD range)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Seal material: Standard NBR, optional FKM (Viton)
- Weight: 18.5g ±0.3g
- Dimensions: 29mm(L) × 25mm(W) × 25mm(H)
- IP rating: IP40 (non-submerged environments)
- Vibration resistance: ≤10Hz with 1.5mm amplitude
- Repeat insertions: ≥50 cycles (tube replacement)
Compact pneumatic tee connector featuring tool-free tube installation and leak-proof design. The 45° angled port configuration enables space-efficient piping layouts in three directions. Nickel-plated brass construction resists corrosion in humid environments, while the double-locking collet mechanism prevents accidental tube disconnection.
- Branch line connections in pneumatic control systems
- Modular automation equipment air distribution
- Robotic arm pneumatic circuit splitting
- Medical device gas line manifolds
- Packaging machine air flow division
Installation note:
Cut tubing ends square and deburr before insertion. For optimal sealing,
insert tubes until they bottom out (audible click). Maximum recommended
torque during threaded port assembly: 1.2N·m. Avoid using in continuous
vibration environments above 15G acceleration.
| Property | Property Value |
|---|---|
| sku | X-APDJ6 |
