Airtac X-APE Connector - T Tee X-APE4
$3.17
Regular price
$10.67
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APE4
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APE T-Type Tee Connector X-APE4 Technical Details
- Model: X-APE4
- Type: T-shaped three-way connector (push-in fitting)
- Port configuration: 1/8" BSPT (G1/8) female threads × 3
- Material: Brass with nickel plating (stainless steel optional)
- Pressure rating: 0.2-1.0 MPa (29-145 psi)
- Temperature range: -5℃ to 80℃ (brass) / -20℃ to 150℃ (SS version)
- Installation type: Push-to-connect (tube retention force: 45N min)
- Tube compatibility: Φ4mm & Φ6mm pneumatic tubing
- Seal material: NBR (Nitrile) standard / FKM (Viton) optional
- Weight: 25g ±2g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H) (body only)
- Surface treatment: Electroless nickel plating (3-5μm)
- Leakage rate: ≤0.1 NL/min at 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-flow T-connector featuring tool-free installation and 360° rotatable ports for flexible piping layouts. The tapered thread design ensures airtight sealing even under pulsating pressure conditions. Internal flow channels are polished to Ra0.8μm for minimal pressure drop.
Common Applications:
- Branch line distribution in pneumatic control systems
- Vacuum circuit splitting for pick-and-place robots
- Modular assembly in semiconductor manufacturing equipment
- Air supply distribution in automotive testing jigs
- Medical gas line branching for hospital equipment
Installation best practice:
Cut tubing ends square (max 0.5° deviation) and deburr before insertion.
For vertical installations, support tubing within 150mm of connector.
Perform pressure test at 1.25× max operating pressure during commissioning.
Compatibility Notice:
Not compatible with ester-based lubricants. Use phosphate-ester resistant grease if needed.
Maximum reconnection cycles: 30 times (with original tubing).
| Property | Property Value |
|---|---|
| sku | X-APE4 |
