Airtac X-APGJ Reducer Straight Connector X-APGJ106
AirTAC X-APGJ106 Reducer Straight Connector Plug Technical Details
- Model: X-APGJ106
- Type: Two-way reducer connector (male thread to female thread)
- Material: Brass with nickel plating (base), NBR/FKM seals
- Thread Specifications: PT1/8 (M5×0.8) male × PT1/4 (M10×1.0) female
- Pressure Rating: 0.05-1.5 MPa (7-217 psi)
- Temperature Range: -20℃ to 80℃ (continuous) / -30℃ to 100℃ (intermittent)
- Torque Resistance: ≤30 N·m
- Seal Compatibility: Compatible with air, water, and non-corrosive gases
- Surface Treatment: Electro-less nickel plating (3-5μm thickness)
- Weight: 15.2g ±0.5g
- Dimensions: 22mm(Length) × 12mm(OD male end) × 16mm(OD female end)
- Thread Engagement: 6mm(min) for both ends
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-machined transition fitting designed for secure stepped pneumatic connections. Features triple-lead thread design for faster assembly and anti-vibration locking grooves. The dual-stage sealing (metal-to-metal primary seal + elastomer secondary seal) ensures zero leakage under dynamic pressure conditions.
- Branch line pressure regulation in compact pneumatic manifolds
- Tool changer interfaces on CNC machines
- Sensor mounting ports requiring size adaptation
- Mobile hydraulic/pneumatic hybrid systems
- Vacuum line transitions in packaging equipment
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Use two wrenches - counter-hold female end while tightening.
Max 1/4 turn past finger-tight. Pressure test after 24hrs curing.
Not recommended for:
- High-pressure pulsation systems (>2Hz cycle rate)
- Direct immersion in phosphate ester fluids
- Applications requiring EN 837-1 pressure vessel compliance
| Property | Property Value |
|---|---|
| sku | X-APGJ106 |
