Airtac X-APHZ Cross Reducing Connector X-APHZ86
AirTAC X-APHZ86 Cross-Type Reducing Tee Fitting Technical Details
- Model: X-APHZ86
- Type: 4-way cross connector with dual-stage reduction
- Primary ports: 2×1/4" NPT (inlet) / 2×1/8" NPT (outlet)
- Thread standard: ANSI B1.20.1 (NPT)
- Material: Brass C3604 with electroless nickel plating (5-8μm)
- Pressure rating: 0.05-1.2 MPa (7-174 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal type: Precision-molded NBR O-rings (Shore A70±5)
- Flow capacity: 200 NL/min @ 0.5 MPa
- Weight: 85g ±3g
- Dimensions: 38mm(L) × 38mm(W) × 38mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: ≤10Hz @ 2.5mm amplitude
Four-way pneumatic manifold designed for space-constrained pneumatic systems requiring flow division with diameter transition. Features asymmetrical port sizing (1/4" to 1/8") for optimized pressure distribution in branch lines. The electropolished internal channels minimize turbulent flow, while the 360° rotatable ports enable flexible plumbing configurations.
- Modular pneumatic control panels with mixed line sizes
- Robotic end-effector tooling air distribution
- CNC machine multi-axis actuator circuits
- Plastic injection molding machine air networks
- Laboratory gas chromatography setups
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads using clockwise winding.
Torque to 12-15 N·m using flank drive sockets. Avoid overtightening
which may deform O-ring grooves. Perform pressure test at 1.5×
working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APHZ86 |
