Airtac X-APKB Connector - Threaded 5 Port X-APKB1004
AirTAC X-APKB1004 Threaded 5-Way Union Fitting Technical Details
- Model: X-APKB1004
- Type: Pneumatic 5-way threaded manifold
- Thread standard: PT1/8 (BSPP) or NPT1/8 (optional)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) / Optional FKM (Fluorocarbon)
- Max operating pressure: 1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Tube compatibility: Ø4mm (5/32") or Ø6mm (1/4") OD pneumatic tubing
- Port configuration: 1 input + 4 outputs (L-shaped flow paths)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Weight: 24.5g ±0.3g
- Dimensions: 28mm(W) × 28mm(D) × 34mm(H)
- Torque resistance: ≤1.5N·m during installation
- Compliance: RoHS 2.0 compliant
Precision-machined flow distribution block featuring corrosion-resistant nickel plating and 90° port orientation. The dual-plane sealing design prevents cross-port leakage even under pressure fluctuations. Includes integrated O-ring grooves for positive seal retention. Compatible with all standard pneumatic fluids including dry air, vacuum, and inert gases.
- Multi-actuator control in assembly line automation
- Modular pneumatic circuit distribution panels
- Medical device gas flow management systems
- Laboratory equipment manifold clusters
- Robotic end-effector pneumatic networks
Installation protocol:
Apply pipe sealant only to male threads (not female ports).
Use backup wrench on hex base during tightening.
Maximum 2 full rotations after hand-tight contact.
Pressure test at 1.5x operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APKB1004 |
