Airtac X-APKG Adapter - Reducing 5-Way Fitting X-APKG86
AirTAC X-APKG86 Reducing Tee Fitting Technical Details
- Model: X-APKG86
- Type: 5-port reducing tee (3-way flow control)
- Material: Lead-free brass (C37700) with nickel plating
- Thread standards: M5×0.8 (Input) / PT1/8 (Outputs)
- Pressure rating: 0.05–1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 120℃
- Flow coefficient (Cv): 0.22
- Leakage rate: ≤3 bubbles/min (ISO 6952)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Weight: 28±2g
- Dimensions: 32mm(L) × 24mm(W) × 19mm(H)
- Surface hardness: ≥HV200
- Certifications: RoHS, REACH, ISO 9001
Precision-machined flow distribution component with asymmetric pressure compensation, featuring corrosion-resistant nickel plating and dual O-ring (NBR 70°) sealing. The stepped port design maintains laminar flow while reducing port sizes, ideal for compact pneumatic circuits requiring pressure differentiation.
- Modular pneumatic manifolds in robotics
- Multi-tool pneumatic distribution stations
- Medical device gas line reducers
- CNC machine tool auxiliary air circuits
- Automated packaging line branch circuits
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 1.2–1.5 N·m torque using 13mm crowfoot wrench.
Avoid overtightening - maximum angular rotation after contact is 120°.
- Works with Ø4/Ø6mm PU tubing (0.8–1.2mm wall thickness)
- Recommended with AirTAC SMC-S-04 quick connectors
- Use AR-10 anti-vibration sleeve for mobile equipment
| Property | Property Value |
|---|---|
| sku | X-APKG86 |
