Airtac X-APKJ Push-In 5-Way Fitting X-APKJ604
AirTAC X-APKJ604 5-Port Insertion Type Connector Specifications
- Model: X-APKJ604
- Type: 5-way connector (1 input, 4 outputs)
- Thread standard: M5×0.8 (metric)
- Material: Nickel-plated brass body + PPS resin sleeve
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 200 L/min (ANR)
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Tube compatibility: Ø4mm & Ø6mm polyurethane/nylon tubes
- Insertion force: ≤50N (with lubricated tube)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Weight: 38g ±2g
- Dimensions: 50mm(L) × 30mm(W) × 25mm(H)
Compact modular manifold connector with color-coded ports for simplified pneumatic circuit assembly. Features dual-stage tube retention system with visual insertion confirmation window. Anti-vibration design maintains stable connections in dynamic environments. Compatible with ISO 12151-2 standard.
- Modular pneumatic control panels
- Robotic end-effector tooling
- Packaging machine manifold systems
- Medical device pneumatic distribution
- Semiconductor handling equipment
Installation protocol:
Cut tubes at 90°±2° using dedicated cutter. Insert until tube end becomes visible in inspection window.
For maintenance: Push sleeve 2.5mm inward while gently pulling tube. Replace seal every 5,000 cycles.
| Property | Property Value |
|---|---|
| sku | X-APKJ604 |
