Airtac X-APMFT All Brass Female Thread Bulkhead Straight Fitting X-APMFT1204
$11.34
Regular price
$18.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APMFT1204
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APMFT1204 Full Brass Bulkhead Female Thread Straight Connector Specifications
- Model: X-APMFT1204
- Material: C3604 Free-cutting brass (lead-free compliant)
- Thread type: Metric internal thread (M5×0.8 female both ends)
- Pressure rating: 1.5 MPa max (217 psi)
- Temperature range: -5℃ to 120℃ (non-freezing environment)
- Surface treatment: Electro-nickel plated (8-12μm thickness)
- Seal configuration: Dual O-ring design (NBR rubber seals)
- Installation torque: Recommended 0.7-1.2 N·m
- Weight: 18.5±0.5g
- Dimensions: 24mm(Length) × 12mm(Hex width) × 12mm(Height)
- Vibration resistance: ≤5G acceleration (10-2000Hz)
- Certifications: RoHS 2.0, REACH SVHC 219
Precision-machined bulkhead connector featuring corrosion-resistant nickel plating and anti-vibration thread design. The dual-seal structure prevents leakage in high-pressure pneumatic systems. Hexagonal body allows 12mm wrench installation with torque control markings.
Typical Applications:
- Pneumatic control panel manifold connections
- CNC machine tool air circuit distribution
- Food packaging equipment sensor mounting
- Industrial robot end effector plumbing
- Compressed air instrumentation lines
Installation note:
Apply PTFE tape on 1.5-2 thread turns maximum. Avoid cross-threading during
panel mounting - align axis perpendicular to mounting surface within ±0.5° tolerance.
Retorque after 48hrs of operation.
| Property | Property Value |
|---|---|
| sku | X-APMFT1204 |
