Airtac X-APP Fitting - Plug X-APP8
AirTAC X-APP8 Tube Plug Connector Technical Details
- Model: X-APP8
- Type: Straight thread-type tube plug
- Material: Nickel-plated brass body
- Thread standard: Metric (M8×1.0)
- Applicable tube OD: Φ8mm (flexible pneumatic tubing)
- Pressure rating: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile)
- Surface treatment: Electroplated zinc-nickel alloy (10-15μm)
- Vibration resistance: ≤10Hz (axial direction)
- Weight: 12g ±0.5g
- Dimensions: 18mm(L) × 8mm(Dia) × 10mm(Wrench flat)
- IP rating: IP40 (dust protected)
- Reusable cycles: ≥500 times
Precision-engineered sealing plug with anti-vibration grooves and dual-stage sealing (thread + O-ring). Features a hexagonal wrench flat for secure installation and chemical-resistant sealing suitable for lubricated air systems. The tapered thread design prevents over-tightening damage.
- Blocking unused ports in pneumatic manifolds
- Maintenance caps for hydraulic test points
- Dust protection in CNC machine tooling stations
- Temporary sealing during pneumatic system repairs
- Pressure vessel safety ports in cleanrooms
Installation protocol:
Apply 0.2-0.5Nm torque using 10mm wrench. Perform leak test at
0.8MPa after installation. Replace O-ring every 3 years under
continuous operation. Not recommended for vacuum systems below -0.1MPa.
| Property | Property Value |
|---|---|
| sku | X-APP8 |
