Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M8
$3.53
Regular price
$11.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APX6M8
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APX6M8 Y-Type Threaded Tee Fitting Technical Details
- Model: X-APX6M8
- Type: Y-shaped pneumatic tee connector (equal-diameter branching)
- Material: Brass with nickel-plated surface
- Thread standard: Metric fine thread (M8×1.0)
- Port configuration: 3 female threaded ports (M8)
- Pressure range: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-rings
- Surface roughness: Ra ≤1.6μm
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Weight: 48±2g
- Dimensions: 25mm(L) × 20mm(W) × 20mm(H)
- Compliance: RoHS 2.0 compliant
Precision-engineered Y-connector featuring symmetrical flow paths with minimal pressure drop. The electroplated finish provides corrosion resistance in humid environments. Designed for leak-free connections in compact pneumatic systems, with hex base for wrench tightening.
Typical Applications:
- Pneumatic circuit branching in robotic end effectors
- Air pressure distribution in packaging machinery
- Modular pneumatic system installations
- Medical device gas line configurations
- Laboratory instrument air supply networks
Installation guidelines:
Apply 2-3 drops of pneumatic sealant (viscosity ≤35 cSt) on threads before assembly.
Tighten to 4-5 N·m torque using 13mm wrench. Avoid overtightening to prevent port deformation.
Compatibility:
Works with Φ6mm tubing (maximum OD 8mm). Not recommended for hydrocarbon-based fluids or pressures exceeding 10 bar continuous operation.
| Property | Property Value |
|---|---|
| sku | X-APX6M8 |
