Airtac X-APZA Cross Four-Way Connector X-APZA10
AirTAC X-APZA10 Cross Tee Fitting Technical Details
- Model: X-APZA10
- Type: 4-way cross connector (female threads on all ports)
- Material: Nylon 66 (PA66) with 30% glass fiber reinforcement
- Thread Standard: BSPP (G) 1/8" (R1/8 optional)
- Operating Pressure: 0.05-1.5 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 60℃
- Seal Material: HNBR (Hydrogenated Nitrile) O-rings
- Port Configuration: 4 female threaded ports (90° orthogonal)
- Surface Finish: Smooth injection-molded with anti-static treatment
- Weight: 28g ±1g
- Dimensions: 31mm(L) × 31mm(W) × 31mm(H) (cube form factor)
- Thread Engagement Depth: 8mm per port
- Flow Capacity: 250 NL/min (at 0.5MPa)
Precision-molded cross manifold featuring leak-proof swirl flow channels, optimized for compact pneumatic distribution systems. The symmetrical design enables 360° rotatable port alignment during installation. Includes built-in particle traps to prevent downstream contamination. Meets ISO 6150-B standard for pneumatic fittings.
- Multi-axis pneumatic tool manifolds
- Modular automation test benches
- Cleanroom equipment air distribution
- Simultaneous actuator control systems
- PLC-controlled pneumatic circuits
Installation Best Practices:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 1.2-1.5 N·m torque using a crowfoot wrench.
Perform pressure test at 1.25× working pressure after assembly.
| Property | Property Value |
|---|---|
| sku | X-APZA10 |
