Airtac X-APZT Full Brass Cross Connector X-APZT10
AirTAC X-APZT10 Full Brass Four-Way Tee Fitting Specifications
- Model: X-APZT10
- Type: Brass 4-way pneumatic manifold
- Thread standard: PT1/8 (BSPP) female threads
- Port configuration: 4 symmetrical outlets (T-style)
- Material: Lead-free brass CW617N
- Surface treatment: Electro-nickel plated (5-8μm)
- Pressure rating: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to 120℃
- Proof pressure: 1.5 MPa
- Seal material: Integrated metal-to-metal sealing
- Weight: 38±2g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H)
- Thread engagement depth: 8mm per port
- Flow coefficient (Cv): 0.12
Precision-machined distribution block featuring quad-directional flow paths with leak-resistant tapered thread design. The compact cube structure enables space-saving installation in clustered pneumatic systems. Corrosion-resistant nickel plating ensures durability in humid environments.
- Pneumatic control panel manifold assemblies
- Air tool power distribution hubs
- Multi-axis actuator synchronization systems
- Laboratory instrumentation air routing
- CNC machine tool pneumatic circuits
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 1.2-1.5 N·m torque using flank drive sockets to prevent
port deformation. Test at 0.6 MPa for 5 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | X-APZT10 |
