Airtac X-ASA Adapter - Tube Throttle Type X-ASA8
AirTAC X-ASA8 Throttle Type Tube Fitting Specifications
- Model: X-ASA8
- Type: Throttle-type push-in fitting with flow control
- Thread size: M5×0.8 (external thread)
- Tube OD compatibility: Ø4mm or Ø6mm (switchable via internal adapter)
- Flow adjustment range: 50-500 mL/min (air), ±10% calibrated
- Max operating pressure: 1.0 MPa
- Leakage rate: <5×10⁻³ Pa·m³/s under 0.5 MPa
- Body material: Nickel-plated brass (standard), SS304 optional
- Seal material: HNBR rubber (-20℃ to 120℃)
- Weight: 28g ±2g (without tube)
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Rotation torque: 0.3-0.6 N·m (recommended tightening)
Precision throttle fitting with 210° adjustable knob for fine flow regulation in pneumatic circuits. Features dual O-ring seals and tool-free tube insertion. The brass body includes a dust shield cap with 3-position click stops for repeatable flow settings. Compatible with air/N₂ (non-lubricated) and vacuum systems.
- Pneumatic cylinder speed control in SMT equipment
- Vacuum pick-and-place end effectors
- Medical gas flow regulation devices
- Laboratory analytical instrument pneumatics
- Beverage dispensing machine pressure balancing
Installation note:
Always install downstream of filters. For optimal performance:
- Cut tube ends square (max 0.5mm deviation)
- Insert tube until "double-click" tactile feedback
- Adjust flow clockwise to reduce (marked ▼)
| Property | Property Value |
|---|---|
| sku | X-ASA8 |
