Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL1001
AirTAC X-ASL1001 Limit-Entry L-Type Fitting Detailed Specifications
- Model: X-ASL1001-(L)
- Type: Limit-entry L-shaped push-in pneumatic fitting
- Material: Brass with nickel plating (stainless steel variant available)
- Thread standard: PT1/8 (BSPP) female threads
- Seal mechanism: Dual O-ring retention system
- Operating pressure: 0.05–1.5 MPa
- Temperature range: -5°C to 60°C
- Tube compatibility: Ø4mm (OD) polyurethane/nylon tubing
- Insertion force: ≤35N (with lubrication)
- Extraction force: 20-80N (tool required for release)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Seal material: NBR (Nitrile rubber)
- Certification: RoHS compliant
- Weight: ~50g
- Dimensions: 40mm(L) × 25mm(W) × 20mm(H)
Premium L-shaped pneumatic connector featuring a fail-safe limit-entry design that prevents accidental tube disconnection. The 45° angled port configuration enables space-efficient plumbing in complex pneumatic circuits. Nickel-plated brass construction ensures corrosion resistance in humid environments while maintaining 500,000+ cycle durability.
- Robotic arm pneumatic tool changers
- CNC machine tool clamping systems
- Pharmaceutical packaging line manifolds
- Semiconductor wafer handling equipment
- Mobile hydraulic control panels
Installation protocol:
Cut tubing ends square, deburr thoroughly, and insert until audible "click".
Perform pull-out force test (≥20N) after installation. Lubricate with silicone grease
(ISO VG1 grade) when used in sub-zero conditions.
| Property | Property Value |
|---|---|
| sku | X-ASL1001 |
