Airtac X-ASL Adapter (L-Type) Restricted Port X-ASL12M12
AirTAC X-ASL12M12 L-Type Restricted Entry Fitting (X-ASL Series)
- Model: X-ASL12M12-(L)
- Type: L-shaped restricted entry (anti-contamination design)
- Thread specification: M12×1.0 male thread (external) with BSPP 1/8" female thread
- Material: Brass (CuZn39Pb3) with nickel plating
- Seal material: NBR/PU hybrid o-ring
- Operating temperature: -20℃ to 80℃
- Pressure range: 0.05-1.5 MPa
- Flow coefficient (Cv): 0.6
- IP rating: IP40 (dust protected)
- Vibration resistance: ≤10-55Hz, 1.5mm amplitude
- Weight: 35g ±2g
- Dimensions:
- Total length: 35mm
- L-arm length: 18mm (threaded portion)
- Body diameter: Φ12mm
- Hex size: 17mm wrench flat
- Compliance: RoHS, REACH
90° angled pneumatic connector featuring patented debris-blocking grooves that prevent particulate ingress. The chrome-plated brass construction ensures corrosion resistance in humid environments, while the dual-material seal prevents air leakage under cyclic pressure. Includes integrated thread locker grooves for secure installation.
- Pneumatic valve manifold interconnections
- Robotic end-effector air supply lines
- CNC machine tool pneumatic circuits
- Food packaging equipment (NSF-compliant version available)
- Semiconductor fab cleanroom systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten - recommended torque 12-15N·m).
Orientation arrow must point toward downstream flow. Compatible with Φ6-8mm tubing.
| Property | Property Value |
|---|---|
| sku | X-ASL12M12 |
