Airtac X-EPGJ Connector - Reducer Straight Connector X-EPGJ106
AirTAC X-EPGJ106 Reducing Straight Through Connector Specifications
- Model: X-EPGJ106 (1/8" Male to 1/4" Female)
- Type: Metric-Imperial thread reducing connector
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) rubber
- Thread standards: BSPP (G) threads
- Male thread end: 1/8" BSPP (G1/8)
- Female thread end: 1/4" BSPP (G1/4)
- Max working pressure: 1.5 MPa (217 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Proof pressure: 3.0 MPa
- Burst pressure: 6.0 MPa
- Weight: 22g ±0.5g
- Dimensions: 24mm (L) × 13.5mm (Male end OD) × 18mm (Female end OD)
- Surface roughness: Ra ≤3.2μm
- Torque specification: 14-16 N·m (123-141 lb-in)
- Compliance: RoHS 2.0 compliant
A precision-machined transition fitting designed for hybrid pneumatic systems requiring metric-to-imperial thread conversion. Features triple-layer nickel plating (5-8μm thickness) for corrosion resistance in humid environments. The tapered thread design with 55° flank angle ensures leak-free connections without thread sealant when properly tightened.
- Retrofitting legacy equipment with modern pneumatic components
- Compressed air line transitions in multi-standard machinery
- Vacuum system plumbing in semiconductor manufacturing
- Mobile hydraulic/pneumatic hybrid systems
- Modular pneumatic circuit prototyping
Installation protocol:
Use a backup wrench on the 14mm hex flats during assembly.
Apply thread sealant only to male threads if system pressure exceeds 1.0 MPa.
Maximum 3 full rotations after hand-tight contact for optimal sealing.
- AirTAC PGJ/PGU/PFC series fittings
- ISO 1179-1 compliant components
- JIS B0203 parallel pipe threads
| Property | Property Value |
|---|---|
| sku | X-EPGJ106 |
