Airtac X-EPGJ Connector - Reducer Straight Connector X-EPGJ108
AirTAC X-EPGJ108 Reducing Straight Fitting Plug Technical Details
- Model: X-EPGJ108
- Type: Metric thread reducing straight connector with plug
- Body material: Brass (CuZn39Pb3) with electroless nickel plating
- Seal material: NBR (Nitrile rubber)
- Thread specifications: M10×1.0 (male) to M8×1.0 (female)
- Pressure rating: 0-1.5 MPa (217.5 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Torque resistance: ≤30 N·m
- Surface hardness: HV 550±50 (plating layer)
- Weight: 15g ±0.5g
- Dimensions: 23mm(Total L) × 16mm(Hex W) × 12mm(Major Ø)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Compliance: RoHS 2011/65/EU
Precision-machined transition fitting for pneumatic systems requiring stepped diameter connections. Features triple-layer corrosion protection (base metal + nickel plating + chromate film) and 360° rotatable installation. The tapered thread design ensures leak-free connections without requiring thread sealant below 1.0 MPa.
- Pneumatic valve manifold conversions
- Air cylinder port adaptation
- Tool-free maintenance systems in packaging lines
- Sensor mounting brackets in automation cells
- Medical gas line reducers
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads when exceeding 0.8 MPa.
Tighten to 12-15 N·m torque using 16mm wrench. Avoid overtightening beyond 180° rotation
after hand-tight contact.
- AirTAC MMF/MF/M series fittings
- ISO 1179-2 metric pipe threads
- Standard 10mm OD polyurethane tubing
| Property | Property Value |
|---|---|
| sku | X-EPGJ108 |
