Airtac X-EPGJ Connector - Reducer Straight Connector X-EPGJ128
AirTAC X-EPGJ128 Reducing Straight Through Plug Specifications
- Model: X-EPGJ128
- Type: Step-down union (male-to-female)
- Material: Brass with nickel plating (CuZn39Pb3)
- Male thread: 1/8" NPT (external)
- Female thread: 1/4" NPT (internal)
- Seal material: NBR/FKM optional
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (NBR) / -20℃ to 150℃ (FKM)
- Surface hardness: HV0.3 ≥130 (nickel layer)
- Weight: 12.5g ±0.3g
- Dimensions: 18mm(Ø) × 21.5mm(L)
- Thread engagement depth: 7.5mm (1/8") / 9.0mm (1/4")
- Torque resistance: ≤29N·m
- Compliance: RoHS 2.0 compliant
Precision-machined transition fitting with dual sealing surfaces (60° cone + flat seat), designed for secure leak-free connections between different pneumatic line sizes. Features anti-vibration knurling and corrosion-resistant finish. The stepped design prevents over-tightening while maintaining 360° rotatability during installation.
- Pneumatic cylinder port adapters
- Compressed air distribution manifolds
- Instrumentation gas line transitions
- Robotic end-effector plumbing
- Vacuum system component interfaces
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (except when using integrated seal).
Tighten to 8-10N·m maximum. Avoid cross-threading by hand-starting rotation
before applying wrench force. Compatible with tube OD: 4mm(1/8") to 6mm(1/4").
| Property | Property Value |
|---|---|
| sku | X-EPGJ128 |
