Airtac X-EPH External Hex Elbow Connector X-EPH1003
AirTAC X-EPH1003 Hexagonal Elbow Joint Technical Details
- Model: X-EPH1003
- Type: External hexagonal elbow joint (swivel type)
- Thread specification: M10x1.5 (male thread)
- Material: Nickel-plated brass body + PPS resin sleeve
- Applicable tube OD: 10mm (flexible pneumatic tubing)
- Max working pressure: 0-1.0 MPa
- Temperature range: -20℃ to 80℃
- Torque resistance: 30-35 Nm (with anti-loosening design)
- Surface hardness: HV300±20 (nickel plating layer)
- Weight: 85g ±2g
- Dimensions: 32mm(L) × 22mm(W) × 22mm(H)
- Rotation angle: 360° continuous rotation capability
- Vibration resistance: 10-2000Hz (MIL-STD-810G compliant)
Precision-engineered swivel joint featuring dual-seal structure (O-ring + metal-to-metal contact) for leak-free performance in high-vibration environments. The hexagonal design allows tool-assisted tightening while the rotating elbow maintains fluid direction accuracy during mechanical movement. Compatible with ISO 16030 standard pneumatic connections.
- Robotic arm end-effector pneumatic lines
- CNC machine tool coolant system connections
- High-cycle packaging machine actuator joints
- Semiconductor wafer handling vacuum systems
- Food-grade pneumatic systems (NSF certified)
Installation protocol:
Use 10mm open-end wrench on hex flats while holding elbow body.
Apply thread sealant (LOCTITE 577 recommended) for permanent installations.
Max 120°C during thermal cycling applications.
| Property | Property Value |
|---|---|
| sku | X-EPH1003 |
