Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF10M12
AirTAC X-EPHF Series Tandem Elbow Joint X-EPHF10M12 Technical Details
- Model: X-EPHF10M12
- Type: Tandem elbow swivel joint (dual-axis rotation)
- Body material: Anodized aluminum alloy (AL6061-T6)
- Thread specification: M12×1.0 male thread (ISO 1179-2 standard)
- Working pressure: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (non-condensing)
- Surface hardness: HV 400±20 (anodized layer)
- Rotational torque: ≤0.3 N·m (at 0.6 MPa)
- Swivel angle: ±25° (dual-axis articulation)
- Leakage rate: ≤3 bubbles/min (ISO 16030 test standard)
- Weight: 108±2g (including sealing components)
- Dimensions: 50mm(L) × 32mm(W) × 32mm(H)
- Port connection: BSPP/G parallel threads (adaptable to NPT with washer)
- Seal material: HNBR rubber (FDA compliant options available)
- Protection rating: IP40 (dust protected)
High-precision tandem elbow joint featuring dual-axis rotation for complex piping layouts. The hexagonal body design allows tool-assisted tightening (14mm wrench size). Nickel-plated brass internal components ensure smooth rotation cycles exceeding 500,000 repetitions. Compatible with air, inert gases, and vacuum systems.
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Semiconductor wafer handling vacuum systems
- Packaging machinery rotary union interfaces
- Medical device pneumatic control loops
- Automated welding gun air supply lines
Installation protocol:
Apply 2-3 drops of pneumatic oil (ISO VG32 grade) on swivel surfaces before initial use.
Tighten with 12-15 N·m torque using calibrated torque wrench. Avoid overtightening
which may deform sealing surfaces. Perform monthly rotation checks in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | X-EPHF10M12 |
