Airtac X-KAPT Pneumatic-Hydraulic Intensifier X-KAPT6301000105T
AirTAC X-KAPT6301000105T Gas-Liquid Intensifier Cylinder Specifications
- Model: X-KAPT6301000105T
- Type: Two-stage gas-liquid combined intensifier
- Bore size: 63mm (air piston) / 50mm (oil cylinder)
- Boost ratio: 1:10 (adjustable via pressure regulation)
- Working pressure:
- Air side: 0.2–0.8 MPa
- Output oil pressure: Up to 20 MPa
- Stroke: 100mm (pre-stroke) + 10mm (boost stroke)
- Operating medium: Filtered air (40μm) + ISO VG68 hydraulic oil
- Weight: 8.7kg ±2% (with standard fittings)
- Dimensions: 360mm(L) × 130mm(W) × 180mm(H)
- Material:
- Cylinder body: Aluminum alloy AL6061-T6
- Piston rod: Chrome-plated SCM435 steel
- Seals: HNBR with wear-resistant coating
- Temperature range: -10℃ to 80℃ (with viscosity compensation)
- Interface sizes:
- Air inlet: G1/4
- Oil port: M16×1.5
- Exhaust: Built-in muffler
- Fluid capacity: 380cm³ (oil reservoir)
- Cycle life: ≥500,000 cycles (under rated pressure)
- Protection rating: IP54 (standard), IP67 optional
High-efficiency hybrid intensifier combining pneumatic energy with hydraulic precision. Features dual-stage pressure amplification with automatic oil replenishment system and anti-cavitation design. The progressive boost control enables smooth transition between rapid approach and high-force pressing phases. Integrated shock absorbers minimize end-stroke impact.
- Sheet metal stamping with controlled deformation rates
- Precision bearing press-fitting in automotive assembly
- Composite material molding with dwell pressure control
- Bolt tensioning in wind turbine maintenance
- Leak testing fixtures for industrial valves
Maintenance note:
Requires monthly oil level inspection (viewing window provided). Use only specified ISO VG68 anti-wear hydraulic oil.
Lubricate guide rods with MIL-PRF-6085 grease every 5,000 cycles. Avoid horizontal installation - maximum allowable
tilt angle is 15°.
| Property | Property Value |
|---|---|
| sku | X-KAPT6301000105T |
