Airtac X-KAPTA Pneumatic-Hydraulic Booster Cylinder X-KAPTA0005000510TF
AirTAC X-KAPTA Hydropneumatic Intensifier Cylinder X-KAPTA0005000510TF Technical Details
- Model: X-KAPTA0005000510TF
- Type: 3-stage gas-liquid combined intensifier
- Bore diameter: 50mm (air piston) / 25mm (oil cylinder)
- Stroke: 100mm (air) + 50mm (oil)
- Max. boost ratio: 10:1 (adjustable via pressure regulation)
- Operating pressure: 0.1-0.7 MPa (air input)
- Output force: Up to 3,900N at 0.5MPa air supply
- Media compatibility: Clean dry air (ISO8573-1) + ISO VG32 hydraulic oil
- Temperature range: -10℃ to 60℃ (air) / 0℃ to 50℃ (oil)
- Port size: G1/4 (air inlet) / M14×1.5 (hydraulic outlet)
- Cycle rate: 50-100 cycles/min (dependent on stroke)
- Weight: 4.8kg (with standard oil filling)
- Dimensions: 230mm(L) × 85mm(W) × 85mm(H)
- Seal material: Polyurethane (air side) / Nitrile rubber (oil side)
- Mounting orientation: Vertical ±15° recommended
High-efficiency hybrid cylinder combining pneumatic speed with hydraulic pressure stability. Features dual-chamber design with automatic oil replenishment system and built-in shock absorber. The chrome-plated piston rod incorporates anti-rotation guidance for precise linear motion. Requires 5μm filtered air and periodic oil level checks (view window included).
- Precision metal forming in stamping presses
- Bearing/shaft assembly with controlled interference fit
- Battery cell compression in EV manufacturing
- Deburring fixtures requiring variable end-force
- Hydraulic tool actuation in explosive environments
Operation note:
Always pre-charge hydraulic chamber to 0.3MPa minimum before initial use.
Avoid continuous holding mode exceeding 30 minutes to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | X-KAPTA0005000510TF |
