Airtac X-KCV Basic Type Vacuum Generator X-KCV05HSCK
AirTAC X-KCV05HSCK Basic Series Vacuum Generator Specifications
- Model: X-KCV05HSCK
- Type: Single-stage ejector with integrated silencer
- Port size: M5 (1/8") threaded ports
- Operating pressure range: 0.25–0.7 MPa
- Vacuum flow rate: 5.5 L/min @ 0.5 MPa
- Maximum vacuum level: -92 kPa (approx. -690 mmHg)
- Air consumption: 14.5 L/min @ 0.5 MPa
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: 5℃ to 60℃
- Weight: 95g ±2%
- Dimensions: 62mm(L) × 25mm(W) × 32mm(H)
- Response time: ≤0.15 sec (vacuum generation)
- Sound level: ≤65 dB(A) with built-in muffler
Compact vacuum generator optimized for rapid suction applications, featuring a streamlined internal flow path design that reduces air turbulence and improves energy efficiency. The integrated silencer minimizes operational noise while maintaining airflow efficiency. Compatible with standard vacuum cups and sensors through its M5 threaded ports.
- PCB handling in electronics assembly lines
- Plastic part positioning in injection molding machines
- Paper feed systems in high-speed printers
- Glass panel transfer in solar module production
- Medical device packaging automation
Installation guidelines:
Maintain horizontal mounting orientation for optimal performance.
Use anti-vibration washers when installing on moving carriages.
Recommended maintenance: Clean filter screen every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | X-KCV05HSCK |
