Airtac X-KCV Basic Type Vacuum Generator X-KCV10HSCK
AirTAC X-KCV Basic Series Vacuum Generator X-KCV10HSCK Technical Details
- Model: X-KCV10HSCK
- Type: Single-stage ejector vacuum generator
- Vacuum level: -88kPa (at 0.5MPa supply)
- Air consumption: 14.5 NL/min (0.5MPa)
- Port size: M5 (1/8") threaded
- Operating pressure: 0.25–0.7 MPa
- Max vacuum flow: 30 L/min
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Temperature range: 5℃ to 60℃
- Noise level: ≤68 dB(A)
- Weight: 0.28 kg
- Dimensions: 70mm(L) × 25mm(W) × 32mm(H)
- Exhaust direction: Radial
- Mounting: Direct piping or bracket installation
High-efficiency compact vacuum generator featuring optimized flow path design for rapid vacuum creation (achieves -80kPa in 0.3s). Integrated silencer reduces operational noise by 30% compared to standard models. The hardened aluminum construction ensures durability in continuous operation cycles.
- PCB handling robots in electronics assembly
- Vacuum chuck systems for CNC machining
- Automated packaging line pick-and-place units
- Medical device component positioning
- Glass panel transfer systems
- Food packaging vacuum suction
Installation note:
Maintain minimum 30cm distance from electromagnetic interference sources.
Always install downstream 5μm filter. Recommended maintenance cycle:
2,000 operating hours or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | X-KCV10HSCK |
