Airtac X-KCV Basic Type Vacuum Generator X-KCV15HSCK
AirTAC X-KCV Basic Series Vacuum Generator X-KCV15HSCK Technical Details
- Model: X-KCV15HSCK (Basic Compact Type)
- Type: Single-stage ejector with integrated silencer
- Vacuum flow rate: 15 L/min @ 0.5 MPa
- Max vacuum level: -88 kPa (-660 mmHg)
- Operating pressure range: 0.25–0.7 MPa
- Air consumption: 28 L/min @ 0.5 MPa
- Port size: 1/8" NPT (M5 optional adapter)
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Operating temperature: 5℃ to 60℃ (non-freezing)
- Weight: 185 g ±5%
- Dimensions: 46mm(W) × 25mm(H) × 82mm(L)
- Sound pressure level: ≤62 dB(A)
- Protection rating: IP40 (dust protected)
- Threaded mounting: M4×0.7 (4 mounting points)
Compact vacuum generator featuring rapid evacuation capability and optimized airflow design. The integrated muffler reduces operational noise while maintaining 92% vacuum efficiency. Its corrosion-resistant construction supports continuous duty cycles in industrial environments. Requires 5μm filtered compressed air (ISO 8573-1 class 4).
- PCB handling in SMT pick-and-place machines
- Glass panel suction in display manufacturing
- Plastic part retention in injection molding automation
- Medical device assembly vacuum tooling
- Food packaging film positioning systems
Installation guidelines:
Mount horizontally with vacuum port facing downward. Maintain minimum 30cm distance from electromagnetic interference sources.
Use anti-vibration washers when installed on moving carriages. Pre-charge system with 0.3 MPa air before vacuum engagement.
| Property | Property Value |
|---|---|
| sku | X-KCV15HSCK |
