Airtac X-KCV Basic Type Vacuum Generator X-KCV20HSCK
AirTAC X-KCV20HSCK Basic Vacuum Generator Technical Specifications
- Model: X-KCV20HSCK
- Type: Compact single-stage vacuum generator
- Port size: M5 (1/8")
- Operating pressure range: 0.2-0.7 MPa (29-102 psi)
- Maximum vacuum flow: 20 L/min (ANR)
- Vacuum level: -84 kPa (-12.2 psi) at 0.5 MPa supply
- Response time: ≤0.15 sec (vacuum generation)
- Weight: 75g ±2g
- Dimensions: 48mm(L) × 22mm(W) × 34mm(H)
- Body material: Aluminum alloy (anodized finish)
- Seal material: Fluororubber (FKM)
- Temperature range: 5℃ to 60℃ (operating), -20℃ to 80℃ (storage)
- Air consumption: 5.3 NL/min @ 0.5 MPa
- Sound level: ≤65 dB(A)
- Protection rating: IP40 (standard configuration)
High-efficiency vacuum generator featuring optimized flow path design for rapid suction establishment. Incorporates built-in silencer and debris-resistant structure. The compact profile enables cluster installations in space-constrained automation setups. Requires clean compressed air (ISO 8573-1:2010 Class 3.4.2) with 5-40μm filtration.
- PCB handling in SMT assembly lines
- Glass panel transfer systems
- Medical device component positioning
- Packaging machine pick-and-place units
- Semiconductor wafer handling robots
Installation best practice:
Maintain minimum 30mm spacing between multiple units for heat dissipation.
Use shock-absorbing mounts in high-cycle applications (>5 operations/sec).
| Property | Property Value |
|---|---|
| sku | X-KCV20HSCK |
