Airtac X-KCV Basic Type Vacuum Generator X-KCV25HSCK
AirTAC X-KCV Standard Vacuum Generator X-KCV25HSCK Technical Specifications
- Model: X-KCV25HSCK
- Type: Single-stage ejector vacuum generator
- Vacuum flow rate: 23 L/min (max) | 16 L/min @ 0.5MPa
- Operating pressure range: 0.25–0.7 MPa
- Vacuum level: -88 kPa (typical at 0.5MPa supply)
- Port sizes: 1/8" NPT (inlet/exhaust) | M5 vacuum port
- Weight: 0.28 kg (with fittings)
- Dimensions: 78mm(L) × 34mm(W) × 40mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 60℃ (non-freezing)
- Noise level: ≤72 dB(A) @ 0.5MPa
- Response time: ≤0.3 sec (vacuum establishment)
- Air consumption: 28 NL/min @ 0.5MPa
- Protection rating: IP40 (standard configuration)
Compact vacuum generator featuring optimized nozzle geometry for rapid vacuum formation and energy efficiency. Integrated silencer reduces exhaust noise by 15% compared to previous generations. The hardened aluminum construction withstands industrial vibration while maintaining precise internal tolerances (±0.01mm critical components).
- PCB handling in SMT assembly lines
- Vacuum gripping systems for robotic pick-and-place
- Medical device packaging seal verification
- Non-porous material handling in food packaging
- Optical lens polishing fixtures
- Semiconductor wafer processing equipment
Installation guidelines:
Mount in any orientation but maintain 50mm clearance from obstructions.
Use 5μm filtration for inlet air. For continuous operation, maintain ambient
humidity below 80% RH. Replace silencer foam (P/N: SF-25H) every 2,000
operational hours in dusty environments.
| Property | Property Value |
|---|---|
| sku | X-KCV25HSCK |
