Airtac 2-Way Solenoid Valve 2W030-08-B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W030-08-B Solenoid Valve Technical Details
- Model: 2W030-08-B
- Type: 2-way direct acting (normally closed/NC)
- Port configuration: G1/8 (ISO228 standard)
- Thread type: BSPP (parallel threads with O-ring seal)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max pressure: 1.5 MPa (217.5 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W | AC: 3.5VA
- Response time: ≤15ms (open/close cycle)
- Seal material: NBR (Nitrile) standard | Optional FKM (Viton®) for high temp
- Fluid compatibility: Compressed air (lubricated/non-lubricated), inert gases
- Ambient temperature: -5℃ to 80℃ (NBR) | -10℃ to 150℃ (FKM option)
- Protection class: IP67 (dust/water resistant)
- Weight: 280g ±5g (with coil)
- Dimensions: 56mm (L) × 32mm (W) × 38mm (H)
- Port spacing: 18mm center-to-center
- Mounting orientation: Any (360° rotatable coil)
High-speed 2-way valve with manual override button, featuring brass body construction with hard anodized aluminum core. Designed for precise on/off control in compact pneumatic systems. Includes LED status indicator (select models) and surge protection circuitry. Requires 5μm filtration (40μm max particle size).
- Automated assembly line clamping mechanisms
- Textile machinery air jet control
- Semiconductor wafer handling vacuum/pressure switching
- Commercial coffee machine steam valves
- Railway brake system pilot controls
Operation notes:
Maintain minimum 1.5x port diameter straight piping upstream.
Use thread sealant only on male threads (PTFE tape prohibited).
Cycle rate ≤5Hz continuous operation. Annual lubrication recommended for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2W030-08-B |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
