Airtac 2-Way Solenoid Valve 2W050-15-F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-15-F Solenoid Valve Specifications
- Model: 2W050-15-F
- Type: 2-position 2-way direct acting (normally closed)
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: ~300g (including coil)
- Dimensions: 70mm(L) × 50mm(W) × 40mm(H)
- Body material: Brass (C3604) with nickel plating
- Seal material: HNBR rubber (improved heat resistance)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤2.8W (DC), ≤3.5VA (AC)
- Protection rating: IP65 (coil protection)
- Port orientation: Horizontal or vertical (flow direction indicated by arrow)
High-flow compact solenoid valve with integrated manual override, featuring improved dust resistance and 30% faster response than previous generation. The dual-chamber design minimizes pressure loss (≤0.05MPa @ 0.5MPa supply). Requires 5μm filtered lubricated air (ISO8573-1 class 4) with recommended maintenance every 2,000,000 cycles.
- Industrial automation pneumatic circuits
- Textile machinery air control systems
- Beverage dispensing equipment
- Semiconductor manufacturing tools
- Automated test bench airflow management
- Cleanroom-compatible devices (low particle emission)
Installation note:
Mount with actuator facing downward in dusty environments. Use flexible tubing connections
to prevent vibration transfer. Lubricate every 6 months with ISO VG32 turbine oil if operating
in continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | 2W050-15-F |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
