Airtac 2-Way Solenoid Valve 2W200-20-B
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W200-20-B Solenoid Valve Specifications
- Model: 2W200-20-B
- Type: 2-position 2-way direct-acting (universal port)
- Port size: PT1/2 (G1/2 optional)
- Port configuration: NAMUR interface compliant
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow coefficient (Cv): 2.5 (Kv: 2.8)
- Weight: 420g ±5% (excluding accessories)
- Dimensions: 90mm(L) × 45mm(W) × 50mm(H)
- Seal material: NBR (Nitrile) / Optional FKM (Viton)
- Temperature range: -20℃ to 70℃ (no freezing)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Mounting orientation: Any (horizontal recommended)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve with manual override, featuring bidirectional flow capability and low-hysteresis spool design. The brass body with hard anodized aluminum sleeve ensures corrosion resistance in humid environments. Compatible with ISO 15407-1 standards, it supports both air and neutral gas media (non-lubricated). Includes LED status indicator and surge protection circuit.
- Pneumatic cylinder control in assembly lines
- Vacuum generator switching in packaging systems
- Coolant flow control for CNC machinery
- Process gas regulation in semiconductor manufacturing
- Dust collector pulse-jet valve systems
Installation guidelines:
Use flexible tubing connections to prevent vibration transfer.
Apply 20-30Nm torque during port installation.
Maintain 85% ≤ RH non-condensing environment.
Perform monthly manual cycling for sticky environments.
Critical notes:
Not compatible with phosphate ester fluids.
Requires 5μm filtration (ISO 8573-1:2010 Class 4).
Minimum 50mm clearance from heat sources.
Use shielded cable for EMI-sensitive applications.
| Property | Property Value |
|---|---|
| sku | 2W200-20-B |
| Port Size | BSPT 3/4 |
| Flow Aperture | <20mm> |
| Coil Voltage | DC24V |
