Airtac 2-Way Solenoid Valve 2W200-20-C
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W200-20-C Solenoid Valve Technical Specifications
- Model: 2W200-20-C
- Type: 2-position 5-way (double solenoid)
- Port size: G1/4 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 400g ±5% (without connectors)
- Dimensions: 60mm(L) × 50mm(W) × 100mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5°C to 80°C (23°F to 176°F)
- Flow capacity: CV 1.3 (Kv 1.5) at 7 bar
- Response time: ≤30ms (at rated voltage)
- Protection rating: IP67 (dust-tight and protected against temporary immersion)
- Housing material: Reinforced PA66 with glass fiber
- Port thread depth: 13mm (minimum engagement)
High-flow directional control valve with dual solenoid operation, featuring optimized flow paths for reduced pressure drop. The hardened stainless steel spool ensures 2 million cycle durability. Compatible with ISO 5599/1 mounting interfaces, suitable for modular pneumatic systems. Requires 5μm filtered air with oil mist lubrication (ISO VG32 or equivalent).
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC tool changers and pallet systems
- Food processing pneumatic circuits (non-contact areas)
- Textile machinery tension control
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (max torque 1.2Nm).
Maintain ambient humidity below 90% RH. For horizontal piping, install drain separator upstream.
Allow 15mm service clearance for manual override operation.
Critical notes:
Do not apply silicone-based lubricants. Cycle rate limited to 5Hz continuous operation.
Always install surge suppressors for DC coils.
| Property | Property Value |
|---|---|
| sku | 2W200-20-C |
| Port Size | BSPT 3/4 |
| Flow Aperture | <20mm> |
| Coil Voltage | AC 110V |
