Airtac 2-Way Solenoid Valve 2W200-20-F
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W200-20-F Solenoid Valve Specifications
- Model: 2W200-20-F
- Type: 2-position 2-way direct-acting (normally closed or open optional)
- Port size: PT1/2 (G1/2 equivalent)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Flow coefficient (Cv): 3.2
- Response time: ≤15ms (at rated voltage)
- Weight: 580g ±5% (with connector)
- Dimensions: 98mm(L) × 52mm(W) × 54mm(H)
- Seal material: High-grade NBR (nitrile butadiene rubber)
- Temperature range: -5℃ to 80℃ (operating fluid/ambient)
- Power consumption: 4.5W (DC), 5.5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Port alignment: Linear flow path design
High-flow solenoid valve with industrial-grade durability, featuring a copper-free aluminum alloy body and corrosion-resistant anodized finish. The direct-acting design ensures reliable operation even with low differential pressure. Optimized coil structure reduces heat generation during continuous duty cycles. Compatible with compressed air and inert gases (N2). Requires 5μm filtration with oil mist lubrication (ISO8573-1 class 4).
- Industrial automation assembly line actuators
- Plastic injection molding machine pneumatic systems
- Food processing equipment air control
- Semiconductor manufacturing gas circuits
- Wastewater treatment plant valve clusters
Installation guidelines:
Mount in any orientation (horizontal recommended for debris prevention).
Use thread sealant on male ports (Teflon tape prohibited). Maintain
20mm minimum clearance around coil for heat dissipation. For AC models,
install surge protection devices in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 2W200-20-F |
| Port Size | BSPT 3/4 |
| Flow Aperture | <20mm> |
| Coil Voltage | DC12V |
