Airtac 2-Way Solenoid Valve 2W250-25-A
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W250-25-A 2-Way Solenoid Valve Technical Details
- Model: 2W250-25-A
- Type: 2/2-way normally closed (direct-acting)
- Port size: G1/4 (BSPP thread conforming to ISO 228-1)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow capacity: 250 l/min (Cv=0.25 at 0.5 MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Seal materials: NBR (standard), optional FKM/Viton®
- Body material: Die-cast aluminum alloy with epoxy coating
- Protection class: IP65 (dust-tight & protected against water jets)
- Electrical connection: DIN43650 Form A connector
- Weight: 450g ±3% (without connector)
- Dimensions: 98mm(L) × 34mm(W) × 47mm(H) (including connector)
High-flow compact solenoid valve featuring manual override capability and zero pressure differential operation. The brass core tube design ensures stable magnetic force distribution, while the optimized spool structure minimizes pressure loss (ΔP≤0.02 MPa). Requires 5μm filtration with oil mist lubrication (ISO 8573-1:2010 Class 4.4.3).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in material handling systems
- Coolant flow regulation for CNC machining centers
- Compressed air management in semiconductor fab tools
- Automated bakery oven door actuators
Installation protocol:
Mount with torque ≤1.5N·m using backup wrench. For horizontal mounting,
orient coil upward. Install downstream of 40μm filter regulator lubricator (FRL) unit.
Perform 5-minute dry cycling before initial operation.
| Property | Property Value |
|---|---|
| sku | 2W250-25-A |
| Port Size | PT 1/8 |
| Flow Aperture | <25 mm> |
| Coil Voltage | AC220V |
