Airtac 2-Way Solenoid Valve 2W250-25-C
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W250-25-C Solenoid Valve Specifications
- Model: 2W250-25-C
- Type: 2-position 2-way normally closed (direct acting)
- Port size: G1/4 (ISO228/1 standard)
- Thread specification: Rc1/4 (PT1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Max working pressure: 1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 4.5W | AC: 5.5VA
- Response time: ≤15ms (open/close)
- Weight: 310g ±5% (including coil)
- Dimensions: 62mm(L) × 42mm(W) × 53mm(H)
- Seal material: Nitrile Butadiene Rubber (NBR) standard | FKM available on request
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP65 (coil protection)
- Fluid compatibility: Compressed air (oil mist lubrication ≤1:13,000)
- Port alignment: Horizontal/vertical (bidirectional installation)
High-flow solenoid valve with direct-acting mechanism for rapid switching in industrial automation systems. Features brass body with hard anodized aluminum coil housing for corrosion resistance. Requires 5μm filtered compressed air with max particle size ≤50μm. Compatible with ISO 8573-1:2010 air quality standards.
- Industrial pneumatic cylinder control systems
- Automated assembly line actuators
- Textile machinery air flow management
- Semiconductor manufacturing equipment
- Food packaging machine pneumatic circuits
- Medical gas control systems (requires FKM seals)
Installation guidelines:
Maintain minimum 20mm clearance around valve body for heat dissipation.
Use copper-free anti-seize compound on threads. Lubricate with ISO VG32
pneumatic oil if operating below -5℃. Replace seals every 5 million cycles
under continuous operation.
| Property | Property Value |
|---|---|
| sku | 2W250-25-C |
| Port Size | PT 1/8 |
| Flow Aperture | <25 mm> |
| Coil Voltage | AC 110V |
