Airtac 2-Way Solenoid Valve 2W250-25-E
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W250-25-E Solenoid Valve Specifications
- Model: 2W250-25-E
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Maximum flow rate: 1800 NL/min (Cv=1.4)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Duty cycle: 100% ED (continuous operation capable)
- Response time: ≤20ms (at rated voltage)
- Weight: 530g ±3% (including coil)
- Dimensions: 130mm(L) × 58mm(W) × 51mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (non-freezing environment)
- Protection rating: IP67 (dust-tight & protected against temporary immersion)
- Port alignment: ISO 5599/1 standard
- Hysteresis: ≤10% of rated voltage
High-flow directional control valve with rugged aluminum alloy body and manual override. Features low power consumption (3.5W @ DC24V) and integrated LED status indicator. Designed for high-cycle applications requiring precise air path switching. Requires 5μm filtered lubricated air (ISO 8573-1 class 3) with 30-50% relative oil mist concentration.
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping/unclamping mechanisms in CNC machining centers
- Vacuum generator control systems
- Textile machinery thread control
- Automotive brake testing equipment
- Plastic injection molding machine ejectors
Installation guidelines:
Mount using M5 mounting brackets (not included). Maintain minimum 15mm
clearance from heat sources. Use copper-free anti-seize compound on port threads.
For horizontal mounting, position coil upright to prevent condensate ingress.
Critical note:
Not compatible with phosphate ester fluids or halogenated hydrocarbons.
Always install downstream of speed controller (flow control valve)
when used with asymmetric actuators.
| Property | Property Value |
|---|---|
| sku | 2W250-25-E |
| Port Size | PT 1/8 |
| Flow Aperture | <25 mm> |
| Coil Voltage | AC24V |
