Airtac 2-Way Solenoid Valve 2W250-25-F
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W250-25-F Solenoid Valve Technical Details
- Model: 2W250-25-F
- Type: 2-position 2-way normally closed (direct acting)
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 2.5
- Response time: ≤15ms (open/close)
- Seal material: FKM (Viton®) for high temp applications
- Temperature range: -10℃ to 150℃ (with FKM seals)
- Protection rating: IP67 (dustproof & waterproof)
- Weight: 380g ±5%
- Dimensions: 78mm(L) × 46mm(W) × 40mm(H)
- Port connection: ISO G thread with O-ring seal
- Electrical connection: DIN43650 Form A with LED indicator
High-flow compact solenoid valve with manual override capability, featuring brass body construction with chrome-plated brass spool for smooth operation. Designed for aggressive duty cycles (up to 50 million operations) with surge protection circuitry. Requires 5μm filtered compressed air with max 1% oil content.
- Plastic injection molding machine clamping systems
- CNC machine tool coolant control
- Food processing pneumatic actuators
- High-temperature furnace gas flow regulation
- Semiconductor wafer handling robotics
Installation guidelines:
Mount in vibration-free environment using included shock-absorbing brackets.
For horizontal installation, ensure exhaust port faces downward. Lubricate O-rings
with silicone grease (DO NOT use petroleum-based lubricants).
| Property | Property Value |
|---|---|
| sku | 2W250-25-F |
| Port Size | PT 1/8 |
| Flow Aperture | <25 mm> |
| Coil Voltage | DC12V |
