Airtac 2KL Solenoid Valve 2KL03006A
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03006A 5/2-Way Solenoid Valve Technical Details
- Model: 2KL03006A
- Type: 5/2-way double solenoid (bi-stable)
- Port configuration: 5 ports (P, A, B, R, S) / 2 positions
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤20ms (at rated voltage)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature range: -5℃ to 60℃ (no freezing)
- Fluid temperature range: -5℃ to 80℃
- Power consumption: DC: 3.5W max / AC: 4.5VA max
- Protection class: IP67 (dustproof & waterproof)
- Weight: 320g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 85mm(H) (excluding connectors)
- Manual override: Built-in emergency button
- Mounting: Direct acting with ISO 15407-1 standard footprint
High-flow solenoid valve with latching function for energy-saving operation, featuring aluminum alloy body with hard anodized finish. Designed for bidirectional cylinder control requiring position memory function. Includes LED status indicator and surge protection circuit. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Robotic arm clamping systems
- Plastic injection molding machines
- Automated assembly line actuators
- Textile machinery tension control
- Bottle capping station pneumatics
Installation guidelines:
Use M5 mounting screws with 0.49-0.69N·m torque. Maintain minimum 30mm
clearance below valve for exhaust flow. For horizontal mounting,
install coil connector facing upward.
Critical note:
Do not apply silicone-based lubricants - use ISO VG32 turbine oil only.
Cycle rate must not exceed 5Hz continuously.
| Property | Property Value |
|---|---|
| sku | 2KL03006A |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
