Airtac 2KL Solenoid Valve 2KL03006B
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03006B Solenoid Valve Technical Details
- Model: 2KL03006B
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.6
- Response time: ≤15ms (at 0.5MPa)
- Weight: ~400g (including coil)
- Dimensions: 85mm(L) × 30mm(W) × 50mm(H)
- Seal material: FKM (Viton® equivalent)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤2.5W (DC) / ≤3.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread standard: ISO 228/1 (BSPP)
Industrial-grade 5-port solenoid valve with manual override and LED status indicator. Features aluminum alloy body with hard anodized finish for chemical resistance. Designed for 500,000+ cycle durability in high-vibration environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 5).
- Pneumatic cylinder control in automated assembly lines
- Dual-acting actuator management for packaging machinery
- Material handling systems with rapid cycling requirements
- Foundry equipment with moderate dust exposure
- Automotive brake testing rigs
Installation guidelines:
Mount with M5 screws (torque ≤0.8N·m). Maintain ambient temperature
below 60℃ when installed horizontally. Use anti-vibration pads in
high-frequency applications. Replace seals every 3M cycles.
| Property | Property Value |
|---|---|
| sku | 2KL03006B |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
