Airtac 2KL Solenoid Valve 2KL05010AI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL05010AI Solenoid Valve Technical Details
- Model: 2KL05010AI
- Type: 5/2-way single solenoid (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 1000 l/min (Cv=1.8)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 380g ±5% (without bracket)
- Dimensions: 56mm(W) × 45mm(H) × 128mm(L)
- Core tube material: Stainless steel SUS304
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with reinforced coil structure, featuring double-chamber sealing technology for leak-free operation. The anodized aluminum body withstands chemical exposure in harsh environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery air circuit control
- Bottle blowing machine actuator systems
- Automated welding equipment
- Lithium battery production line automation
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain minimum 50mm
clearance from heat sources. Use anti-vibration pads in high-cycle
applications (>5Hz operation). Lubricate with ISO VG32 turbine oil
if pneumatic system isn't pre-lubricated.
| Property | Property Value |
|---|---|
| sku | 2KL05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
