Airtac 2KL Solenoid Valve 2KL05010B
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL05010B Solenoid Valve Technical Specifications
- Model: 2KL05010B
- Type: 5/2-way single solenoid (monostable)
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤30ms (actuation), ≤20ms (release)
- Flow capacity: CV 1.2 / KV 1.4
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature: -5℃ to 60℃ (operating fluid temp 0-50℃)
- Weight: 320g ±5g (without connector)
- Dimensions: 60mm(L) × 40mm(W) × 82mm(H)
- Port thread depth: 12mm (internal threaded ports)
- Protection class: IP65 (dust-tight, water jet resistant)
- Service life: ≥10 million cycles (at rated conditions)
High-flow directional control valve with manual override, featuring brass body construction with anodized aluminum solenoid housing. Designed for rapid cycling applications requiring precise directional control in compressed air systems. Includes LED status indicator and surge protection circuitry. Requires 5μm filtration with air lubricator for optimal performance.
- Pneumatic cylinder sequencing in automotive assembly lines
- Rotary actuator control in packaging machinery
- Clamping system automation in CNC workstations
- Material handling systems (conveyor diverters)
- Textile machinery air flow management
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws. Maintain minimum
15mm clearance above coil for heat dissipation. Use PTFE tape on port threads
with 1.5-2 full rotations. Perform monthly manual cycling to prevent seal sticking.
| Property | Property Value |
|---|---|
| sku | 2KL05010B |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
